Eaton Electrical BQC230230 1 Inch CTL Class Type BQC Plug-On Circuit Breaker
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$86.99/ea
Usually available within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cutler-Hammer / Eaton
Mfg Catalog # BQC230230
World Electric Part # 756

Specifications

  • Special Features: Includes rejection tab feature
  • Interrupt Rating: 10 kAIC
  • Type: Type BQC 1-Inch CTL plug-on circuit breaker
  • Wire Size: #14-4 AWG Cu/Al
  • Circuit Breaker Type: BQ
  • Used With: Type BR Loadcenters
  • Main Circuit Breaker: BQC
  • Mounting Method: Plug-on
  • Voltage Rating: 120/240 V
  • Amperage Rating: (2) Two-Pole 30A
  • Trip Type: Common breaker trip
  • Number Of Poles: Four-pole

General

  • UPC: 786676371896
  • Product Length/Depth: 3 IN
  • Product Height: 3 IN
  • Product Width: 2 IN
  • Product Weight: .9 LB
  • Compliances: Federal Specifications Classification W-C375
  • Certifications: UL 489
  • Catalog Notes: All Type BD Duplex and BQ Quadplex circuit breakers carry listing for HACR applications. All 15 and 20 ampere single poles are switch duty rated.

Categories

Overview

UPC 78667637189
Product Description Eaton BR thermal magnetic circuit breaker,Type BQC 1-Inch CTL plug-on circuit breaker,Includes rejection tab feature,(2) Two-Pole 30 A,10 kAIC,Four-pole,120/240V,BQC,Common breaker trip,#14-4 AWG Cu/Al,BQC,Type BR Loadcenters
GTiN 00786676371896
Length 3 in
Voltage 120/240 Volt
Type Type BQC 1-Inch CTL Plug-on Circuit Breaker
Mounting Type Plug-On
Weight .9 lb
Wire Size 14-4 AWG
Standard Federal Specifications Classification W-C375,UL 489
Family Brand Name Eaton
Circuit Breaker Type BQ
Amperage 30 Amp
Trip Type Common Breaker Trip
Number of Poles 4 Pole
Interrupt Rating 10 kA
Blade Dimensions 3.0000 IN X 2.0000 IN X 3.0000 IN
