Eaton Electrical BWH2125 Type BW Main Circuit Breaker
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$116.99/ea
Usually available within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cutler-Hammer / Eaton
Mfg Catalog # BWH2125
World Electric Part # 1754

Specifications

  • Interrupt Rating: 25 kAIC
  • Type: Main circuit breaker
  • Wire Size: #2 AWG-300 kcmil Cu/Al
  • Used With: MBT48B125BTS,
  • Main Circuit Breaker: BR
  • Circuit Breaker Frame Type: BWH
  • Voltage Rating: 120/240 V
  • Amperage Rating: 125A
  • Number Of Poles: Two-pole

General

  • UPC: 786676460439
  • Product Length/Depth: 6.25 IN
  • Product Height: 5.25 IN
  • Product Width: 5.25 IN
  • Product Weight: 2.75 LB
  • Warranty: Limited lifetime residential, 1 year commercial
  • Compliances: Federal Specifications Classification W-C375
  • Certifications: UL 489
  • Catalog Notes: Series combination rating with Types BD, BR, BQ, BQC and GFCB is 22,000 AIC with BRH main and 25,000 AIC with BWH main.

Overview

UPC 78667646043
Product Description Eaton Type BR Main Circuit Breaker,Main circuit breaker,125 A,25 kAIC,Two-pole,120/240 V,BR,#2 AWG-300 kcmil Cu/Al,BWH,MBT48B125BTS,
GTiN 00786676460439
Length 6.25 in
Width 5.25 in
Color Black
Voltage 120/240 Volt
Type Main Circuit Breaker
Height 5.25 in
Weight 2.75 lb
Wire Size 2 AWG
Standard Federal Specifications Classification W-C375,UL 489
Family Brand Name Eaton
Amperage 125 Amp
Blade Dimensions 6.2500 IN X 5.2500 IN X 5.2500 IN
Number of Poles 2 Pole
Interrupt Rating 25 kA
