Hubbell Wiring Devices HBL9432C 30 Amp 125/250 Volt 3-Pole 4-Wire NEMA 14-30P Black Nylon Straight Blade Plug

Features

• Catalog number, ratings and certifications molded in face
• Gripping ribs provide secure gripping area
• Supertough nylon housing

Specifications

• Country of Origin: US
• Current / Amperage Rating: 30 A
• Dimensions: 4.5 in x 3.38 in x 2.37 in
• Each - Height: 3.418 in
• Each - Length: 5.168 in
• Each - Width: 3.168 in
• Height: 2.37 in
• Horsepower - Maximum: 2
• Industry Standard(s): Certified to CSA;UL Listed File E1706
• Length: 4.5 in
• Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 HB;Environmental - IP Suitability - IP20;Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
• Show Add To ProjectList: Yes
• Amperage Rating: 30 A
• Color: Black
• NEMA Rating: 14-30P
• Number of Poles: 3-Pole
• Number of Wires: 4-Wire
• Size: 4.5 in x 3.38 in x 2.37 in
• Standard: Certified to CSA; UL Listed File E1706
• Type: Plug
• Voltage Rating: 125; 250 (unece.unit.VLT; unece.unit.VLT)
• Wattage: 7500 W
• Wire Size: #12 AWG to #4 AWG
• Voltage Rating Description: 125/250 V
• Width: 3.38 in

Certifications

• EU RoHS Indicator: Contact Manufacturer
