ILSCO AK-350 UL/CSA Listed 350 MCM 1/0 AWG Main Range 350 MCM 4 AWG Tap Range Aluminum Split Bolt
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$62.99/ea
Usually available within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # AK-350
World Electric Part # 1934

Specifications

  • UPC Code: 78366900836
  • UNSPSC Code: 39121408
  • Dual Rated: TRUE
  • Conductor Range CU Stranded (Primary, run, main, line): 350 kcmil - 1/0 Str COMPACT
  • Conductor Size CU (Primary, run, main, line): 350 kcmil,300 kcmil,250 kcmil,4/0 Str,3/0 Str,2/0 Str,1/0 Str COMPACT
  • Conductor Range AL Stranded (Primary, run, main, line): 350 kcmil - 1/0 Str COMPACT
  • Conductor Size AL (Primary, run, main, line): 350 kcmil,300 kcmil,250 kcmil,4/0 Str,3/0 Str,2/0 Str,1/0 Str COMPACT
  • Conductor Range CU Stranded (Secondary, tap, load): 350 kcmil - 4 Str
  • Conductor Size CU (Secondary, tap, load): 350 kcmil,300 kcmil,250 kcmil,4/0 Str,3/0 Str,2/0 Str,1/0 Str,1 Str,2 Str,3 Str,4 Str
  • Conductor Range AL Stranded (Secondary, tap, load): 350 kcmil - 4 Str
  • Conductor Size AL (Secondary, tap, load): 350 kcmil,300 kcmil,250 kcmil,4/0 Str,3/0 Str,2/0 Str,1/0 Str,1 Str,2 Str,3 Str,4 Str
  • Drive Size Main: 1-1/2,1-11/16
  • Drive Type Main: External Hex
  • Number of Wire Binding Screws per Port: 1
  • Wire Binding Torque: 650
  • Length (IN): 3.24
  • Width (IN): 1.69
  • Height (IN): 1.5
  • Weight (LB): 0.4562
  • Material: Aluminum
  • Conductor Material: Copper,Aluminum
  • Connector Finish: Tin
  • Color: Silver
  • Direct Burial: FALSE
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • CSA File Number: 72632
  • CSA Standard: C22.2 No. 65,C22.2 No. 188
  • UL Control Number: 670B
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Connection: Mechanical
  • Conductor Type: Solid,Stranded
  • Number of Conductors: 1
  • Number of Poles: 1
  • Number of Ports / Wireways: 1
  • Number of Ports Main: 1
  • Bag Quantity: 1

Overview

UPC 78366900836
Product Description ILSCO Split Bolt, Mechanical connection, Dual Rated, Aluminum material, Tin plated connector, UL 486A/B Listed, C22.2 No. 65, C22.2 No. 188, Copper/Aluminum Primary Conductor 350 kcmil - 1/0 Str COMPACT, Copper/Aluminum Secondary Conductor 350 kcmil - 4 Str, 1 conductors, 1 ports/wireways, Drive Type Main 1-1/2, 1-11/16 External Hex, rated for 35 kV, primary color Silver, 1 poles,
GTiN 00783669008364
Type AK:AL/CU SPLIT BOLT
Material Aluminum
Applications Split Bolt
Temperature Rating 90 C
Family Brand Name ILSCO
Sub Brand ILSCO
Finish Tin Plated
Color Silver
Voltage 35,000 Volt
Number of Conductors 1
TC Connection Mechanical
